OUT-PERFORM LEAD-ACID UNINTERRUPTIBLE POWER SUPPLY DEVICES
Longer Battery Life. Extended Runtime. Smaller Footprint.
-
LONGER RUNTIME
guaranteed 6 minutes of runtime at full load
-
3X LONGER LIFESPAN
7 Years maintenance-free life
-
75% SMALLER & LIGHTER
than traditional VRLA (Lead Acid) UPS solution
-
RAPID RECHARGE TIME
1-hour recharge to 90%
-
30% LONGER CYCLE LIFE
at a given Depth of Discharge (DoD)
INCREASE ROI
Save 8 RU Per Cabinet
Because Rack Space is Money
- The AC6000 lithium-ion UPS is designed to utilize less space on power redundancies in server racks.
- An efficient, effective, and reliable server rack battery backup solution.
Cut OPEX by 20%
- Use less power
- Save on shipping & handling
- Buy fewer batteries
PERFORMANCE AT A GLANCE
Get full performance overview at a glance
- Full state of health and charge
- Controls protects and informs
- Thermal management of cells
Take Monitoring and Performance Management Remote
- Supports Serial & SNMP
- Remote HTTP dashboard
- Supports IPv4 and IPv6
- Multifunction LCD panel
- Reports critical performance metrics
WHY ENCONNEX
The Enconnex Difference Innovation. Speed to Market. Scalability.
Enconnex is at the forefront of technological evolution. We build the future of technology one innovation at a time.
Innovation
Our innovations push the IT
Infrastructure industry forward.
Speed to Market
We beat the competition to market
every time.
Scalability
Mass deployment on a global scale
is our specialty.
SPECS
AC6000 UPS specifications
- Voltage Single Phase208/240 VAC(selectable)
- International Voltage230VAC (selectable)
- Frequency45 -65Hz auto sensing
- Capacity6000 W
- AC Current Rating30A, 32A, 50A
- Power Factor> 0.97
- Input Connection (select one)L6-30P, CS8264/5,
IEC 60309 332C/P6,
or Hardwire
- Voltage Single Phase 208/240 VAC (selectable)
- International Voltage 230 VAC (selectable)
- Frequency 50/60Hz (selectable)
- Topology Line Interactive
- Static Transfer Speed <10ms
- Efficiency >93%
- Rated Current @ 208V 24A with L6-30; 37A with CS8264/5 or hardwire
- Overload Capacity 110% for 1 minute
- Crest factor 2.1:1 (6kW)
- THD in UPS mode Voltage 1.9% Voltage
- Voltage Regulation -bypass mode Maintains voltage range of +/-10%
- Step Down Transformer Compatibility AC6000 is compatible with step down transformers
- Battery TypeLithium-ion 1.0 kW-h
- Recharge Time60 minutes to 90% 120 minutes to 100%
- Expected Cycle Life2000 + cycles (charge - discharge)
- Backup Time6 minutes Full Load (6000W) 12 minutes Half Load (3000W)
- Battery ProtectionDischarge, Overcharge, Thermal
- Surge Energy Rating 215 Joules, Filtering - 1kV Diff; 2kV Comm. Per IEC 61000-4-5 Class A; meets FCC Part 15 Class A
- Interface Ports RS232, Ethernet and REPO Contact Closure
- SNMP V2.0, V3.0 Yes - full function status & control
- Internet Dashboard Yes - full function status & control
- Control Panel Multi function LCD status and conditions
- Audible Alarm Audible alarms based on condition
- Flash firmware updates Yes - register upon delivery
- Emergency Power Off (EPO) Yes - N.O. / N.C
- Automated Orderly Shut Down Server side application feature
- Dimensions3.5 (2U) H x 19.0 W x 32.0 D in 8.89 H x 48.26 W x 81.28 D cm
- Weight 85 lbs. (shipping weight 105 lbs.)
- ColorBlack Face, Silver Body
- EnclosureZinc plated steel, complies with NEMA 1 and UL Type-1
- Operating Temperature Range0° C to 40° C (32° to 104° F)
- Storage Temperature Range-20° C to 60° C (-4° to 140° F
- Humidity0% to 95% Non-Condensing
- Heat Generation (BTU/Hr.)1307
- CoolingTemperature monitored fans - rear exhaust
- Regulatory Approvals UL 1778, UL 991, UL 1998 EN 55032 CISPR 32 FCC Part 15 - Class A IEC 60555.2 IEC 61000-2-2 IEC 61000-3-2, -3 IEC 61000-4-2, -3, -4, -5, -6, -8 EN 62040-1, -2, -3 EU Directive 2014/30/EU UN-DOT 38.3 IEC 62619 IEC 62133-2
- Standard Warranty 3 years repair or replacement including battery
- Optional Warranty 2 years extension including battery (5 years total)
